產(chǎn)品詳細介紹
機號
|
傳動方式
|
轉(zhuǎn)速
r/min |
序號
|
流量
m3/h |
全壓
Pa |
內(nèi)效率
% |
內(nèi)功率
kW |
所需功率
kW |
電動機
|
|
型號
|
功率
kW |
|||||||||
2.8
|
A
|
2900
|
1
2 3 4 5 6 7 8 |
1131
1310 1480 1659 1928 2007 2177 2356 |
994
966 933 887 835 770 702 606 |
69.3
73.2 75.5 76.8 76.9 75.6 73.2 69.3 |
0.45
0.48 0.51 0.53 0.55 0.57 0.58 0.57 |
0.67
0.72 0.71 0.74 0.77 0.79 0.81 0.80 |
Y90S-2
(B35) |
1.5
|
3.2
|
A
|
2900
|
1
2 3 4 5 6 7 8 |
1688
1955 2209 2476 2729 2996 3250 3517 |
1300
1263 1220 1160 1091 1006 918 792 |
69.3
73.2 75.5 76.8 76.9 75.6 73.2 69.3 |
0.88
0.93 0.99 1.03 1.07 1.10 1.13 1.11 |
1.23
1.31 1.38 1.34 1.39 1.43 1.47 1.45 |
Y90L-2
(B35) |
2.2
|
3.2
|
A
|
1450
|
1
2 3 4 5 6 7 8 |
844
978 1104 1238 1365 1498 1625 1758 |
324
315 304 289 272 251 229 198 |
69.3
73.2 75.5 76.8 76.9 75.6 73.2 69.3 |
0.11
0.12 0.12 0.13 0.13 0.14 0.14 0.14 |
0.16
0.17 0.19 0.19 0.20 0.21 0.21 0.21 |
Y90S-4
(B35) |
1.1
|
3.6
|
A
|
2900
|
1
2 3 4 5 6 7 8 |
2664
3045 3405 3786 4146 4527 4887 5268 |
1578
1531 1481 1419 1343 1256 1144 989 |
69.3
73.2 75.5 76.8 76.9 75.6 73.2 69.3 |
1.56
1.65 1.73 1.81 1.86 1.92 1.95 1.94 |
2.03
2.15 2.25 2.35 2.42 2.50 2.53 2.52 |
Y100L-2
(B35) |
3
|
3.6
|
A
|
1450
|
1
2 3 4 5 6 7 8 |
1332
1522 1703 1893 2073 2263 2444 2643 |
393
381 369 353 335 313 285 247 |
69.3
73.2 75.5 76.8 76.9 75.6 73.2 69.3 |
0.20
0.21 0.22 0.23 0.23 0.24 0.24 0.24 |
0.29
0.31 0.33 0.34 0.35 0.36 0.36 0.36 |
Y90S-4
(B35) |
1.1
|
4
|
A
|
2900
|
1
2 3 4 5 6 7 8 |
4012
4506 4973 5468 5962 6457 6924 7419 |
2014
1969 1915 1830 1723 1606 1459 1320 |
77
80.3 82.5 84.1 84.6 83.7 81.4 77.5 |
2.89
3.05 3.18 3.28 3.35 3.42 3.43 3.49 |
3.47
3.66 3.82 3.94 4.02 4.11 4.11 4.19 |
Y132S1-2
(B35) |
5.5
|
4
|
A
|
1450
|
1
2 3 4 5 6 7 8 |
2006
2253 2487 2734 2981 3228 3462 3709 |
501
490 476 455 429 400 363 329 |
77
80.3 82.5 84.1 84.6 83.7 81.4 77.5 |
0.36
0.38 0.40 0.41 0.42 0.43 0.43 0.44 |
0.54
0.57 0.60 0.62 0.63 0.64 0.64 0.66 |
Y90S-4
(B35) |
1.1
|
4.5
|
A
|
2900
|
1
2 3 4 5 6 7 8 |
5712
6416 7081 7785 8489 9194 9859 10562 |
2554
2497 2428 2320 2184 2036 1849 1673 |
77
80.3 82.5 84.1 84.6 83.7 81.4 77.5 |
5.21
5.49 5.74 5.92 6.04 6.17 6.17 6.30 |
6.00
6.32 6.60 6.81 6.95 7.09 7.10 7.24 |
Y132S2-2
(B35) |
7.5
|
4.5
|
A
|
1450
|
1
2 3 4 5 6 7 8 |
2856
3208 3540 3893 4245 4597 4929 5281 |
634
620 603 577 543 506 460 416 |
77
80.3 82.5 84.1 84.6 83.7 81.4 77.5 |
0.65
0.69 0.72 0.74 0.76 0.77 0.77 0.79 |
0.91
0.96 1.00 1.04 1.06 1.08 1.08 1.10 |
Y90S-4
(B35) |
1.1
|
5
|
A
|
2900
|
1
2 3 4 5 6 7 8 |
7728
8855 9928 11054 12128 13255 14328 15455 |
3187
3145 3074 2962 2792 2367 2335 2019 |
77.6
81.0 84.7 86 86.1 84.6 82.1 77.6 |
8.72
9.35 9.90 10.47 10.82 11.07 11.22 11.09 |
10.02
10.76 11.39 12.04 12.44 12.72 12.90 12.75 |
Y160M2-2
(B35) |
15
|
5
|
A
|
1450
|
1
2 3 4 5 6 7 8 |
3864
4427 4964 5527 6064 6628 7164 7728 |
790
780 762 735 693 637 580 502 |
77.6
81.8 84.7 86 86.1 84.6 82.1 77.6 |
1.09
1.17 1.24 1.31 1.35 1.38 1.40 1.39 |
1.42
1.52 1.61 1.70 1.76 1.80 1.82 1.80 |
Y100L1-4
(B35) |
2.2
|
6
|
A
|
1450
|
1
2 3 4 5 6 7 8 |
6677
7650 8578 9551 10478 11452 12379 13353 |
1139
1124 1099 1059 999 919 836 724 |
77.6
81.8 84.7 86 86.1 84.6 82.1 77.6 |
2.71
2.91 3.08 3.26 3.36 3.44 3.49 3.45 |
3.25
3.49 3.70 3.91 4.04 4.13 4.19 4.14 |
Y112M-4
(B35) |
4
|
6
|
A
|
960
|
1
2 3 4 5 6 7 8 |
4420
5065 5679 6324 6938 7582 8196 8841 |
498
492 481 463 437 402 366 317 |
498
492 481 463 437 402 366 317 |
0.79
0.84 0.89 0.94 0.98 1.00 1.01 1.00 |
1.10
1.18 1.25 1.32 1.37 1.40 1.32 1.30 |
Y100L-6
(B35) |
1.5
|
6
|
C
|
2240
|
1
2 3 4 5 6 7 8 |
10314
11818 13251 14755 16187 17692 19124 20628 |
2734
2698 2637 2541 2396 2202 2004 1733 |
77.6
81.8 84.7 86 86.1 84.6 82.1 77.6 |
10.00
10.73 11.35 12.00 12.41 12.69 12.87 12.71 |
12.10
12.98 13.74 14.53 15.02 15.36 15.57 15.39 |
Y160L-4
|
15
|
6
|
C
|
2000
|
1
2 3 4 5 6 7 8 |
9209
10552 11831 13174 14453 15796 17075 18418 |
2176
2147 2099 2022 1907 1753 1595 1380 |
77.6
81.8 84.7 86 86.1 84.6 82.1 77.6 |
7.11
7.64 8.08 8.54 8.83 9.03 9.16 9.05 |
8.61
9.24 9.78 10.34 0.69 10.93 11.09 10.95 |
Y160M-4
|
11
|
6
|
C
|
1800
|
1
2 3 4 5 6 7 8 |
8288
9497 10648 11856 13008 14216 15367 16576 |
1760
1736 1697 1635 1542 1418 1291 1116 |
77.6
81.8 84.7 86 86.1 4.6 82.1 77.6 |
5.1
95.5 75.8 96.2 6.4 46.5 86.6 86.60 |
6.2
86.7 47.1 37.5 47.7 97.9 8.0 87.98 |
Y132M-4
|
7.5
|
6
|
C
|
1600
|
1
2 3 4 5 6 7 8 |
7367
8442 9465 10539 11562 12637 13660 14734 |
1389
1370 1339 1291 1217 1119 1019 881 |
77.6
81.8 84.7 86 86.1 84.6 82.1 77.6 |
3.64
3.91 4.14 4.37 4.52 4.62 4.69 4.63 |
4.60
4.95 .23 5.53 5.71 .84 5.92 5.85 |
Y132S-4
|
5.5
|
6
|
C
|
1250
|
1
2 3 4 5 6 7 8 |
5756
6595 7395 8234 9033 9873 10672 11511 |
846
835 816 786 742 682 621 537 |
77.6
81.8 84.7 86 86.1 84.6 82.1 77.6 |
1.74
1.86 1.97 2.09 2.16 2.20 2.34 2.21 |
2.38
2.55 2.49 2.63 2.72 2.79 2.82 2.79 |
Y100L2-4
|
3
|
6
|
C
|
1120
|
1
2 3 4 5 6 7 8 |
5157
5909 6626 7378 8094 8846 9562 10314 |
679
670 655 631 595 547 498 431 |
77.6
81.8 84.7 86 86.1 84.6 82.1 77.6 |
1.25
1.34 1.42 1.50 1.55 1.59 1.61 1.59 |
1.71
1.83 1.94 2.05 2.12 2.17 2.20 2.17 |
Y100L1-4
|
2.2
|
6
|
C
|
1000
|
1
2 3 4 5 6 7 8 |
4605
5276 5916 6587 7227 7898 8538 9209 |
541
534 522 503 474 436 397 344 |
77.6
81.8 84.7 86 86.1 84.6 82.1 77.6 |
0.89
0.95 1.01 1.07 1.10 1.13 .14 1.13 |
1.31
1.31 1.38 1.46 1.51 1.54 1.57 1.55 |
Y100L1-4
|
2.2
|
6
|
C
|
900
|
1
2 3 4 5 6 7 8 |
4144
4749 5324 5928 6504 7108 7684 8288 |
436
432 422 407 384 353 322 278 |
77.6
81.8 84.7 86 86.1 84.6 82.1 77.6 |
0.65
0.70 0.74 0.780 .80 0.82 0.83 0.82 |
0.96
1.03 1.09 1.15 1.19 1.21 1.23 1.22 |
Y90L-4
|
1.5
|
6
|
C
|
800
|
1
2 3 4 5 6 7 8 |
3684
4221 4733 5270 5781 6319 6830 7367 |
346
341 334 322 303 279 254 220 |
77.6
81.8 84.7 86 86.1 84.6 82.1 77.6 |
0.46
0.49 0.52 0.55 0.57 0.58 0.59 0.58 |
0.72
0.72 0.76 0.81 0.83 0.85 0.86 0.85 |
Y90S-4
|
1.1
|
6
|
D
|
1450
|
1
2 3 4 5 6 7 8 |
6677
7650 8578 9551 10478 11452 12379 13353 |
1139
1124 1099 1059 999 919 836 724 |
77.6
81.8 84.7 86 86.1 84.6 82.1 77.6 |
2.7
12.91 3.08 3.26 3.36 3.44 3.49 3.45 |
3.32
3.56 .77 3.99 4.12 4.21 4.27 4.22 |
Y112M2-4
|
4
|
6
|
D
|
960
|
1
2 3 4 5 6 7 8 |
4420
5065 5679 6324 6938 7582 8196 8841 |
498
492 481 463 437 402 366 317 |
77.6
81.8 4.7 86 86.1 84.6 82.1 77.6 |
0.79
0.84 0.89 0.94 0.98 1.00 1.01 1.00 |
1.12
1.21 1.28 1.35 1.39 1.32 1.34 1.33 |
Y100L-6
|
1.5
|
8
|
C
|
1800
|
1
2 3 4 5 6 7 |
19646
22511 25240 28105 30834 33699 36427 |
3143
3101 3032 2920 2754 2531 2302 |
77.6
81.8 84.7 86 86.1 84.6 82.1 |
21.85
23.46 24.83 26.25 27.12 7.74 28.13 |
26.45
28.39 30.05 31.77 32.83 33.58 34.05 |
Y200L1-2
|
30
|
Y200L2-2
|
37
|
|||||||||
8
|
C
|
1600
|
1
2 3 4 5 6 7 |
17463
20010 22435 24982 27408 29954 32380 |
2478
2445 2390 2303 2171 1996 1816 |
77.6
81.8 84.7 86 86.18 4.68 2.1 |
15.35
16.47 17.44 18.43 19.05 19.49 19.76 |
18.58
19.94 21.10 22.31 23.06 23.59 23.92 |
Y180M-2
|
22
|
Y200L1-2
|
30
|
|||||||||
8
|
C
|
1250
|
1
2 3 4 5 6 7 |
7968
9130 10236 11398 12504 13666 14773 |
512
506 494 476 449 413 376 |
77.6
81.8 84.7 86 86.1 84.6 82.1 |
1.46
1.56 .66 1.75 1.81 1.85 1.88 |
1.93
2.08 2.20 2.32 2.4 2.45 2.49 |
Y160M-4
|
11
|
8
|
C
|
1120
|
1
2 3 4 5 6 7 |
12224
14007 15705 17487 19185 20968 22666 |
1209
1193 1166 1124 1060 975 887 |
77.6
81.8 84.7 86 86.1 84.6 82.1 |
5.26
5.65 5.98 6.32 6.53 6.68 6.78 |
6.37
6.84 7.24 7.65 7.91 8.09 8.20 |
Y132M-4
|
7.5
|
Y160M-4
|
11
|
|||||||||
8
|
C
|
1000
|
1
2 3 4 5 6 7 |
10914
12506 14022 15614 17130 18721 20237 |
963
950 929 895 844 777 707 |
77.6
81.8 84.7 86 86.1 84.6 82.1 |
3.75
4.02 4.26 4.50 4.65 4.76 4.82 |
4.73
5.08 5.38 5.68 5.87 5.76 5.84 |
Y132S-4
|
5.5
|
Y132M-4
|
7.5
|
|||||||||
8
|
C
|
900
|
1
2 3 4 5 6 7 |
9823
11255 12620 14052 15417 16849 18213 |
779
769 752 725 683 629 572 |
77.6
81.8 84.7 86 86.1 84. 82.1 |
2.73
2.93 3.10 3.28 3.39 3.47 3.52 |
3.45
3.70 3.92 4.14 4.28 4.38 4.44 |
Y112M-4
|
4
|
Y132S-4
|
5.5
|
|||||||||
8
|
C
|
800
|
1
2 3 4 5 6 7 |
8732
10005 11217 12491 13704 14977 16190 |
615
607 594 572 540 496 452 |
77.6
81.8 84.7 86 86.1 84.6 82.1 |
1.92
2.06 2.18 2.30 2.38 2.44 2.47 |
2.42
2.60 2.75 2.91 3.01 3.08 3.12 |
Y100L2-4
|
3
|
8
|
C
|
710
|
1
2 3 4 5 6 7 |
7749
8880 9956 11085 12162 13292 14368 |
485
478 468 450 425 391 356 |
77.6
81.8 84.7 86 86.1 84.6 82.1 |
1.34
1.44 1.52 1.61 1.66 1.70 1.73 |
1.84
1.97 2.08 2.20 2.28 2.33 2.36 |
Y100L1-4
|
2.2
|
Y100L2-4
|
3
|
|||||||||
8
|
C
|
630
|
1
2 3 4 5 6 7 |
6876
7879 8834 9837 10791 11794 12749 |
381
376 368 355 334 308 280 |
77.6
81.8 84.76 86.1 84.6 82.1 |
0.94
1.01 1.06 1.13 1.16 1.19 1.21 |
1.38
1.38 1.46 1.54 1.59 1.63 1.65 |
Y100L1-4
|
2.2
|
8
|
D
|
1450
|
1
2 3 4 5 6 |
15826
17134 20332 22640 24838 27146 29344 |
2032
2005 1960 1888 1781 1638 1490 |
77.6
81.8 84.7 86 86.1 84.6 82.1 |
11.42
12.26 12.98 13.72 14.18 14.50 14.71 |
13.41
14.39 15.23 16.1 16.64 17.02 17.26 |
Y180M-4
|
18.5
|
8
|
D
|
960
|
1
2 3 4 5 6 7 |
10478
12006 13261 14989 16444 17972 19428 |
887
875 856 825 778 715 651 |
77.6
81.8 84.7 86 86.1 84.6 82.1 |
3.32
3.563 .77 3.98 4.11 4.21 4.27 |
4.06
4.36 4.61 4.88 5.04 5.15 5.23 |
Y132M2-6
|
5.5
|
8
|
D
|
730
|
1
2 3 4 5 6 7 |
7968
9130 10236 11398 12504 13666 14773 |
512
506 494 476 449 413 376 |
77.6
81.8 84.7 86 86.1 84.6 82.1 |
1.46
1.56 .66 1.75 1.81 1.85 1.88 |
1.93
2.08 2.20 2.32 2.4 2.45 2.49 |
Y132M-8
|
3
|
10
|
C
|
1250
|
1
2 3 4 5 6 |
34863
37953 41044 43690 46262 48797 |
2373
2341 2247 2138 2018 1877 |
86.7
88.7 89 88.2 86.6 84.2 |
26.27
27.59 28.57 29.20 29.73 30.02 |
31.80
33.40 34.58 35.335 35.99 36.34 |
Y225S-4
|
37
|
10
|
C
|
1120
|
1
2 3 4 5 6 |
31237
340006 36775 39146 41451 43722 |
1902
1877 1801 1714 1618 1505 |
86.7
88.7 89 88.2 86.6 84.2 |
18.90
19.85 20.55 21.00 21.38 21.59 |
22.87
24.02 24.87 25.43 25.89 26.14 |
Y200L-4
|
30
|
10
|
C
|
1000
|
1
2 3 4 5 6 |
27890
30363 32835 34952 37010 39038 |
1514
1494 1434 1364 1288 1199 |
86.7
88.7 89 88.2 86.6 84.2 |
13.45
14.13 14.63 14.95 15.22 15.37 |
16.28
17.10 17.70 18.10 18.43 18.60 |
Y180M-4
|
18.5
|
10
|
C
|
900
|
1
2 3 4 5 6 |
25101
27326 29551 31457 33309 35134 |
1225
1209 1161 1104 1042 970 |
86.7
88.7 89 88.2 86.6 84.2 |
9.81
10.30 10.66 1090 11.10 11.20 |
11.87
12.47 12.91 13.19 13.43 13.56 |
Y160L-4
|
15
|
10
|
C
|
800
|
1
2 3 4 5 6 |
22312
24290 26268 27961 29608 31230 |
967
954 916 872 823 766 |
86.7
88.7 89 88.2 86.6 84.2 |
6.89
7.23 7.49 7.65 7.79 7.87 |
8.34
8.76 9.07 9.27 9.43 9.53 |
Y160M-4
|
11
|
10
|
C
|
710
|
1
2 3 4 5 6 |
19802
21557 23313 24816 26277 27717 |
761
751 721 686 648 603 |
86.7
88.7 89 88.2 86.6 84.2 |
4.81
5.06 5.23 5.535 5.45 5.50 |
5.83
6.12 6.34 6.48 6.59 6.66 |
Y132M-4
|
7.5
|
10
|
C
|
630
|
1
2 3 4 5 6 |
17571
19128 20686 22019 23316 24594 |
599
591 568 540 510 475 |
86.7
88.7 89 88.2 86.6 84.2 |
3.36
3.53 3.66 3.74 3.81 3.84 |
4.25
4.46 4.62 4.72 4.81 4.85 |
Y132S-4
|
5.5
|
10
|
C
|
560
|
1
2 3 4 5 6 |
15618
17003 18387 19573 20725 21861 |
473
467 448 426 403 375 |
86.7
88.7 89 88.2 86.6 84.2 |
2.36
2.48 2.57 2.63 2.67 2.70 |
2.98
3.13 3.24 3.32 3.38 3.41 |
Y112M-4
|
4
|
10
|
C
|
500
|
1
2 3 4 5 6 |
13945
15181 16417 17476 18505 19519 |
377
372 357 340 321 299 |
86.6
88.7 89 88.2 86.6 84.2 |
1.68
1.77 1.83 1.87 1.90 1.92 |
2.30
2.42 2.50 2.56 2.40 2.43 |
Y100L2-4
|
3
|
10
|
D
|
1450
|
1
2 3 4 5 6 |
40441
44026 47611 50680 53664 56605 |
3202
3159 3032 2884 2722 2532 |
86.7
88.7 89 88.2 86.6 84.2 |
41.00
43.07 44.59 45.58 46.40 46.86 |
48.12
50.53 52.33 53.49 54.45 54.98 |
Y250M-4
|
55
|
10
|
D
|
960
|
1
2 3 4 5 6 |
26775
29148 31521 33554 35529 37476 |
1395
1376 1321 1257 1187 1104 |
86.7
88.7 89 88.2 86.6 84.2 |
11.9
12.5 12.94 13.23 13.47 13.60 |
13.96
14.67 15.18 15.52 15.80 15.96 |
Y200L1-6
|
18.5
|
10
|
D
|
730
|
1
2 3 4 5 6 |
20360
22164 23969 25515 27017 28497 |
805
794 762 725 685 637 |
86.7
88.7 89 88.2 86.6 84.2 |
5.23v5.50
5.69 5.82 5.92 5.98 |
6.14
6.45 6.68 6.82 6.95 7.02 |
Y160L-8
|
7.5
|
12
|
C
|
1120
|
1
2 3 4 5 6 |
53978
58763 63548 67645 71627 75552 |
2746
2710 2601 2474 2335 2172 |
86.7
88.7 89 88.2 86.2 84.2 |
47.02
49.38 51.13 52.27 53.21 53.73 |
56.92
59.78 61.90 63.27 64.41 65.04 |
Y280S-4
|
75
|
12
|
C
|
1000
|
1
2 3 4 5 6 |
48195
52467 56739 60397 63953 67457 |
2185
2156 2070 1969 1859 1729 |
86.7
88.7 89 88.2 86.2 84.2 |
33.47
35.15 36.40 37.20 37.88 38.25 |
40.51
42.55 44.05 45.03 45.85 46.30 |
Y225M-4
|
45
|
Y250M-4
|
55
|
|||||||||
12
|
C
|
900
|
1
2 3 4 5 6 |
43375
47220 51065 54357 57557 60712 |
1767
1744 1674 1593 1504 1399 |
86.7
88.7 89 8.2 86.2 84.2 |
24.40
25.62 26.53 27.12 27.61 27.88 |
29.53
31.02 32.12 32.83 33.42 33.75 |
Y250M-6
|
37
|
12
|
C
|
800
|
1
2 3 4 5 6 |
38556
41973 45391 48317 51162 53966 |
1395
1376 1321 1257 1187 1104 |
86.7
88.7 89 88.2 86.2 84.2 |
17.14
18.00 18.63 19.05 19.39 19.58 |
20.74
21.79 22.56 23.06 23.47 23.70 |
Y200L2-6
|
22
|
Y225M-6
|
30
|
|||||||||
12
|
C
|
710
|
1
2 3 4 5 6 |
34218
37251 40284 42882 45406 47895 |
1097
1083 1040 989 934 869 |
86.7
88.7 89 88.2 86.2 84.2 |
11.98
12.58 13.03 13.32 13.56 13.69 |
14.50
15.23 15.77 16.12 16.41 16.57 |
Y200L1-6
|
18.5
|
12
|
C
|
630
|
1
2 3 4 5 6 |
30362
33054 35745 38050 40290 42498 |
863
852 818 778 735 684 |
86.7
88.7 89 88.2 86.2 84.2 |
8.37
8.79 9.10 9.30 9.47 9.56 |
10.13
10.64 11.02 11.26 11.46 11.58 |
Y180L-6
|
15
|
12
|
C
|
560
|
1
2 3 4 5 6 |
26989
29381 31774 33822 35813 37776 |
682
673 646 615 580 540 |
86.7
88.7 89 88.2 86.2 84.2 |
5.88
6.17 6.39 6.53 6.65 6.72 |
7.11
7.47 7.74 7.91 8.05 8.13 |
Y160M-6
|
7.5
|
Y160L-6
|
11
|
|||||||||
12
|
C
|
500
|
1
2 3 4 5 6 |
24097
26233 28369 30198 31976 33728 |
543
536 515 490 462 430 |
86.7
88.7 89 88.2 86.2 84.2 |
4.18
4.39 4.55 4.65 4.73 4.78 |
5.28
5.55 5.75 5.87 5.98 5.79 |
Y160M-6
|
7.5
|
12
|
C
|
450
|
1
2 3 4 5 6 |
21687
23610 25532 27178 28778 30356 |
440
434 417 397 374 348 |
86.7
88.7 89 88. 86.2 84.2 |
3.05
3.20 3.32 3.39 3.45 3.49 |
3.85
4.05 4.19 4.28 4.36 4.40 |
Y132M1-6
|
4
|
Y132M2-6
|
5.5
|
|||||||||
12
|
C
|
400
|
1
2 3 4 5 6 |
19278
20986 22695 24158 25581 26983 |
347
343 329 313 296 275 |
86.7
8.7 89 88.2 86.2 84.2 |
2.14
2.25 2.33 2.38 2.42 2.45 |
2.71
2.84 2.9 4.01 3.06 3.09 |
Y132S-6
|
3
|
12
|
D
|
960
|
1
2 3 4 5 6 |
46267
50368 54469 57981 61395 64759 |
2013
1986 1906 1814 1712 1593 |
86.7
88.7 89 88.2 86.6 84.2 |
29.61
31.10 32.20 32.91 33.51 33.84 |
34.75
36.49 37.79 38.62 39.323 39.71 |
Y280S-6
|
45
|
12
|
D
|
730
|
1
2 3 4 5 6 |
35182
38301 41419 44090 46685 49244 |
1160
1145 1099 1046 987 919 |
86.7
88.7 89 88.2 86.6 84.2 |
13.02
13.67 14.16 14.47 14.73 14.88 |
15.28
16.05 16.61 16.98 17.29 17.46 |
Y225S-8
|
18.5
|
16
|
B
|
900
|
1
2 3 4 5 6 |
102810
111930 121040 128840 136430 143910 |
3157
3115 2990 2844 2684 2497 |
86.7
88.7 89 88.2 86.2 84.2 |
102.81
107.98 111.8 114.28 116.35 117.48 |
124.45
130.70 135.33 138.33 140.84 142.20 |
Y315L2-6
|
132
|
Y315M-6
|
160
|
|||||||||
16
|
B
|
800
|
1
2 3 4 5 6 |
91392
99493 107590 114530 121270 127920 |
2489
2456 2357 2242 2117 1969 |
86.7
88.7 89 88.2 86.2 84.2 |
72.21
75.84 78.53 80.27 81.72 82.52 |
87.41
91.81 95.06 97.16 98.92 99.89 |
Y315L1-6
|
110
|
16
|
B
|
710
|
1
2 3 4 5 6 |
81110
88300 95490 101640 107630 113520 |
1957
1931 1853 1763 1664 1549 |
86.7
88.7 89 88.2 86.2 84.2 |
53.02 54.89 56.11 57.12 57.68 |
61.10
64.18 66.45 67.92 69.15 69.83 |
Y315S-6
|
75
|
16
|
B
|
630
|
1
2 3 4 5 6 |
71971
78351 84730 90193 95503 100730 |
1538
1518 1457 1386 1309 1218 |
86.7
88.7 89 88.2 86.2 84.2 |
35.27
37.04 38.35 39.2 39.91 40.30 |
42.69
44.84 46.42 47.45 48.31 48.78 |
Y280M-
|
55
|
16
|
B
|
560
|
1
2 3 4 5 6 |
63974
69645 75316 80172 84892 89544 |
1214
1198 1150 1094 1033 961 |
86.7
88.7 89 88.2 86.2 84.2 |
24.77
26.01 29.93 27.53 28.03 28.30 |
29.98
31.49 32.60 33.33 33.93 34.26 |
Y250M-6
|
37
|
16
|
B
|
500
|
1
2 3 4 5 6 |
57120
62183 67246 71582 75796 79950 |
967
954 916 872 823 766 |
86.7
88.7 89 88.2 86.2 84.2 |
17.63
18.52 19.17 19.60 19.95 20.15 |
21.34
22.41 23.21 23.72 24.15 24.39 |
Y225M-6
|
30
|
16
|
B
|
450
|
1
2 3 4 5 6 |
51408
55965 60521 64423 68216 71955 |
783
773 742 706 666 620 |
86.7
88.7 89 88.2 86.2 84.2 |
12.85
13.50 13.98 14.29 14.54 14.69 |
15.56
16.34 16.92 17.29 17.61 17.78 |
Y200L1-6
|
18.5
|
16
|
B
|
400
|
1
2 3 4 5 6 |
45696
49746 53797 57265 60637 63960 |
618
610 586 557 526 490 |
86.7
88.7 89 88.2 86.2 84.2 |
9.03
9.48 9.82 10.03 10.21 10.31 |
10.93
11.48 11.88 12.15 12.36 12.48 |
Y180L-6
|
15
|
16
|
B
|
355
|
1
2 3 4 5 6 |
40555
44150 47745 50823 53815 56764 |
487
480 461 439 414 386 |
86.7
88.7 89 88.2 86.2 84.2 |
6.31
6.63 6.86 7.01 7.14 7.21 |
7.64
8.02 8.31 8.49 8.64 8.73 |
Y10L-6
|
11
|
16
|
B
|
315
|
1
2 3 4 5 6 |
35985
39175 42365 45096 47751 50368 |
383
378 363 345 326 303 |
86.7
88.7 89 88.2 86.2 84.2 |
4.41
4.63 4.79 4.90 4.99 5.04 |
5.57
5.85 5.80 5.93 6.04 6.10 |
Y160M-6
|
7.5
|
20
|
B
|
710
|
1
2 3 4 5 6 |
158410
172460 186500 198520 210210 221730 |
3069
3029 2907 2765 2609 2427 |
86.7
88.7 89 88.2 86.2 84.2 |
154.04
161.79 167.51 171.23 174.33 176.03 |
186.46
195.84 202.76 207.27 211.02 213.08 |
Y355-8
|
220
|
20
|
B
|
630
|
1
2 3 4 5 6 |
140560
153020 165480 176150 186530 196750 |
2411
2379 2284 2172 2050 1908 |
86.7
88.7 89 88.2 86.2 84.2 |
107.62
113.03 117.03 119.62 121.79 122.98 |
130.27
136.81 141.65 144.79 147.43 148.86 |
Y355-8
|
160
|
20
|
B
|
560
|
1
2 3 4 5 6 |
124950
136020 147100 156580 165800 174890 |
1902
1877 1801 1714 1618 1505 |
86.7
88.7 89 88.2 86.2 84.2 |
75.59
79.39 82.20 84.02 85.54 86.37 |
91.50
96.10 99.51 01.71 03.54 104.55 |
Y315L2-8
|
110
|
20
|
B
|
500
|
1
2 3 4 5 6 |
111560
121450 131340 139800 148040 156150 |
1514
1494 1434 1364 1288 1199 |
86.7
88.7 89 88.2 86.2 84.2 |
53.80
56.51 58.51 59.80 60.89 61.48 |
65.13
38.40 70.82 72.39 73.70 74.42 |
Y315M-8
|
75
|
20
|
B
|
450
|
1
2 3 4 5 6 |
100400
109300 118200 125820 133230 140530 |
1225
1209 1161 1104 1042 970 |
86.7
88.7 89 88.2 86.2 84.2 |
39.22
41.19 42.65 43.60 44.39 44.82 |
47.48
49.86 51.63 52.77 53.73 54.25 |
Y315S-8
|
55
|
20
|
B
|
400
|
1
2 3 4 5 6 |
89250
97161 105070 111840 118430 124920 |
967
954 916 827 823 766 |
86.7
88.7 89 88.2 86.2 84.2 |
27.55
28.93 29.96 30.62 31.17 31.48 |
33.34
35.02 36.26 37.06 37.73 38.10 |
Y280S-8
|
37
|
20
|
B
|
355
|
1
2 3 4 5 6 |
79209
86230 93252 99264 105100 110860 |
761
751 721 686 648 603 |
86.7
88.7 89 88.2 86.2 84.2 |
19.26
20.22 20.94 21.40 21.79 22.00 |
23.31
24.48 25.35 25.91 26.38 26.64 |
Y250M-8
|
30
|
20
|
B
|
315
|
1
2 3 4 5 6 |
70284
76514 82744 88079 93265 98376 |
599
591 568 540 510 475 |
86.7
88.7 89 88.2 86.2 84.2 |
13.45
14.13 14.63 14.95 15.22 15.37 |
16.28
17.10 17.71 18.10 18.43 18.61 |
Y225M-8
|
22
|
20
|
B
|
280
|
1
2 3 4 5 6 |
62475
68013 73551 78293 82902 87445 |
473
467 448 426 403 375 |
86.7
88.7 89 88.2 86.2 84.2 |
9.45
9.92 10.27 10.50 10.69 10.80 |
11.44
12.01 12.44 12.71 12.94 13.07 |
Y200L-8
|
15
|
20
|
B
|
250
|
1
2 3 4 5 6 |
55781
60726 65670 69904 74020 78076 |
377
372 357 340 321 299 |
86.7
88.7 89 88.2 86.2 84.2 |
6.73
7.06 7.31 7.48 7.61 7.68 |
8.14
8.55 8.85 9.05 9.21 9.30 |
Y180L-8
|
11
|
